AIRdesign UFO Ultralight Flying Object

AIRdesign UFO Ultralight Flying Object

¥25000原价:¥35000
    • Ultralight Dyneema riserswith incorporating a 3-line configuration (A,B,C) with accelerator

    详情描述

    设计特点:

    • RAM-AIR-STRUTS:self-inflating ribs for more stability

    • Ultralight Dyneema riserswith incorporating a 3-line configuration (A,B,C) with accelerator

    • Polyamide rods in leadingedge for enhanced performance

    • 3D-cut leading edge

    • Light-weight construction(Skytex27, unsheathed lines, lightweight risers)

    • Edging tapes integrationon ribs for durability

    • Rapid descent manoeuvrecapable (big-ears, b-stall, spiral)

    • Excellent startingbehaviour

    • Very small packing volume

    • Glide angle around 7,trim speed at 38km/h (at 75kg) to 43km/h (accelerated)

    Technical Details

    SIZE

    14

    16

    AREA FLAT  (m²)

    14,50

    15,99

    AREA  PROJECTED (m²)

    12,13

    13,37

    SPAN FLAT  (m)

    7,86

    8,25

    SPAN  PROJECTED (m)

    6,08

    6,38

    ASPECT  RATIO FLAT

    4,26

    4,26

    ASPECT  RATIO PROJ.

    3,04

    3,04

    CELLS

    6,00

    6,00

    PANELS  UPPERSURFACE

    35,00

    35,00

    TOTAL LINE  LENGTH

    226,00

    237,00

    TOTAL LINES

    222,00

    222,00

    WEIGHT (kg)

    1,60

    1,70

    V-TRIM/V-MAX  (km/h) with 75 kg

    39/45

    38/43

    LTF/EN  CATEGORY

    EN-926-1

    EN-926-1

    TAKE OFF  WEIGHT (kg)

    50-120

    55-120

    Materials:

    Sail, Ribs: Skytex 27classic II Soft/Hard, Dominico 20D

    Lines: Edelrid 8000/U-360,280,190,130,090,070

    Riser:LIROS – D-Pro 4mm – 1300daN

    颜色:


    UFO is available in "LITE" colours as standard.

    The UFO can be customised with a different colourof design stripes and trailing edge.

    The main top surface and leading edge is offered in white only.
