AIRdesign EAZY LTF/EN A

AIRdesign EAZY LTF/EN A

¥19800原价:¥25000
    EAZY Launch Technique with the A-Riser

    详情描述

    设计特点:

    To take-off grabthe A-risers between the ‘EAZY LAUNCH’ marks, this is a little but lower thanmay be considered ‘normal’ to some pilots. This position prevents the canopyfrom collapsing if you pull too hard on the A-risers and makes take-off simpleevery time, especially for students or beginners

    The A-lines for bigears are attached to separate risers. The marking ‘EAR’ make them easy tofind.

    The B-risers aremarked with a bold ` B ´, to make sure the right ones are used.

    This is a webbinglink which connects the B and C risers. This webbing prevents the risers fromtwisting and simplifies sorting out the risers and lines.

    The risers of theEAZY have three main riser connection, A, B, and C. Only the outer A-line isattached separately for big ears.

    The risers aredesigned with many of the features developed for our performance gliders butretain a simplicity that helps you during the first steps into our sport.

    RazorEdge

    3D-Cut undNose-Wire

    BrakeGathering & Brake Shifting

    Additional DesignDetails

    Technical Details

    SIZES

    XXS

    XS

    S

    M

    L

    AREA FLAT (m²)

    19,85

    21,92

    24,70

    27,17

    29,37

    AREA PROJECTED (m²)

    16,90

    18,66

    21,03

    23,13

    25,00

    SPAN FLAT (m)

    10,03

    10,54

    11,18

    11,73

    12,20

    SPAN PROJECTED (m)

    8,02

    8,43

    8,95

    9,38

    9,76

    ASPECT RATIO FLAT

    5,1

    5,1

    5,1

    5,1

    5,1

    ASPECT RATIO PROJ.

    3,8

    3,8

    3,8

    3,8

    3,8

    CELLS

    38

    38

    38

    38

    38

    TOTAL LINE LENGTH

    251

    264

    280

    294

    306

    TOTAL LINES

    214

    214

    214

    214

    214

    LINE DIAMETERS

    1/1.2/1.8

    WEIGHT (kg)

    4,5

    4,8

    5,3

    5,7

    6

    WEIGHT (kg) SUPERLIGHT

    3,1

    3,3

    3,8

    4,2

    4,5

    V-TRIM/V-MAX (km/h)

    37/48

    37/48

    37/48

    37/48

    37/48

    V-TRIM/V-MAX (km/h) upper weight range

    40/50

    LTF/EN CATEGORY

    A

    A

    A

    A

    A

    TAKE OFF WEIGHT (kg)

    50-65*

    55-75

    70-90

    80-105

    100-125

    TAKE OFF WEIGHT (kg)

    65-80**

    * Size XXS for schooling 50-65 kg

    **Size XXS extended weight-range 65-80 kg


     Sail:

    Top sail: Dominico DOKDO-30DMF(WR)

    Bottom sail: Dominico DOKDO-30DMF(WR)

    Ribs: Dominico 30D hard



    Lines:

    Top lines: Liros DSL70

    Middle lines: Liros PPSL120

    Main lines: Edelrid 7343-280



    颜色:


    You can design your ownglider using our custom colour picker. Stand out from the gaggle with your owncolour combination.

    To get a quote and estimated delivery time for your custom colour simply copyand email the linkof the colourpicker to your local distributor.
